2026 Honda Pilot

Trims

6 configurations

Select a trim to see its specs and equipment.

2026 Honda Pilot

Sport

From $42,195

Horsepower
285
City MPG
19
Highway MPG
27
Engine
3.5-Liter V6
Horsepower
285 hp
Torque
262 lb-ft
Drivetrain
Front-Wheel Drive (Standard), AWD Available
Transmission
10-Speed Automatic Transmission (10AT) with Paddle Shifters
City / highway MPG
19 / 27
Seating
8 seats
Wheel size
20 in
Ground clearance
7.3 in
Cargo, seats up
18.6 cu ft
Towing capacity
3500 lb

Standard equipment

  • Google built-in (3-Years Unlimited Data Plan)
  • 12.3-Inch Color Touchscreen
  • 10.2-Inch Digital Instrument Cluster
  • Power Lift Tailgate
  • Honda Sensing Suite
  • Apple CarPlay and Android Auto Compatibility
  • Tri-Zone Automatic Climate Control
  • LED Headlights with Auto On/Off
  • LED Fog Lights
  • Gloss Black Roof Rails
  • Dual Gloss Black Exhaust Finishers

The trims, side by side.

Scroll sideways to see every trim →

"Optional" means the feature needs an upgrade or package.

6 of 6 trims
2026 Honda Pilot · Full trim comparison
Trim
Sport
EX-L
TrailSport
Touring
Touring Blackout
Elite
Starting price$42,195$44,495$50,395$51,095$52,295$53,495
City / Hwy / Combined (MPG)19 / 27 / 2219 / 27 / 2218 / 23 / 2019 / 27 / 2219 / 27 / 2219 / 27 / 22
Horsepower285 hp285 hp285 hp285 hp285 hp285 hp
Seating capacity8 seats8 seats7 seats8 seats8 seats8 seats
SportEX-LTrailSportTouringTouring BlackoutElite
DrivetrainFront-Wheel Drive (Standard), AWD AvailableFront-Wheel Drive (Standard), AWD Available2nd-Gen Intelligent Variable Torque Management (i-VTM4) AWD System2nd-Gen Intelligent Variable Torque Management (i-VTM4) AWD System2nd-Gen Intelligent Variable Torque Management (i-VTM4) AWD System2nd-Gen Intelligent Variable Torque Management (i-VTM4) AWD System
Transmission10-Speed Automatic Transmission (10AT) with Paddle Shifters10-Speed Automatic Transmission (10AT) with Paddle Shifters10-Speed Automatic Transmission (10AT) with Paddle Shifters10-Speed Automatic Transmission (10AT) with Paddle Shifters10-Speed Automatic Transmission (10AT) with Paddle Shifters10-Speed Automatic Transmission (10AT) with Paddle Shifters
Name3.5-Liter V63.5-Liter V63.5-Liter V63.5-Liter V63.5-Liter V63.5-Liter V6
TypeV6V6V6V6V6V6
Displacement cc347134713471347134713471
Fuel injectionDirect Fuel InjectionDirect Fuel InjectionDirect Fuel InjectionDirect Fuel InjectionDirect Fuel InjectionDirect Fuel Injection
Horsepower285285285285285285
Horsepower RPM610061006100610061006100
Torque lb ft262262262262262262
Torque RPM500050005000500050005000
Compression ratio11.5:111.5:111.5:111.5:111.5:111.5:1
Redline RPM650065006500650065006500
Features
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
  • Eco Assist System
  • Variable Cylinder Management (VCM)
  • Active Control Engine Mount System (ACM)
  • Active Noise Cancellation (ANC)
  • Idle-Stop
Displacement l3.53.53.53.53.53.5
Auto start stopYesYesYesYesYesYes
Fuel typeGasolineGasolineGasolineGasolineGasolineGasoline
SportEX-LTrailSportTouringTouring BlackoutElite
City MPG191918191919
Highway MPG272723272727
Combined MPG222220222222
NoteRatings for 2WD; AWD is 19/25/21Ratings for 2WD; AWD is 19/25/21Ratings for 2WD; AWD is 19/25/21Ratings for 2WD; AWD is 19/25/21Ratings for 2WD; AWD is 19/25/21Ratings for 2WD; AWD is 19/25/21
SportEX-LTrailSportTouringTouring BlackoutElite
Length (in)200.1200.1200.4200.1200.1200.1
Width (in)78.578.578.578.578.578.5
Height (in)717172717171
Wheelbase (in)113.8113.8113.8113.8113.8113.8
Ground clearance (in)7.37.38.37.37.37.3
Cargo volume (cu ft)18.618.618.618.618.618.6
Max cargo volume (cu ft)878787878787
Passenger volume (cu ft)158.4158.4158.4158.4158.4158.4
Track front (in)67.567.567.567.567.567.5
Track rear (in)67.867.867.867.867.867.8
Turning circle ft37.737.737.737.737.737.7
Width with mirrors (in)909090909090
SportEX-LTrailSportTouringTouring BlackoutElite
Cargo volume max (cu ft)878787878787
Cargo volume seats up (cu ft)18.618.618.618.618.618.6
Curb weight lb403040304030403040304030
Fuel tank gallons18.518.518.518.518.518.5
Headroom front (in)40.540.540.540.540.540.5
Headroom rear (in)40.240.240.240.240.240.2
Hip room front (in)58.458.458.458.458.458.4
Hip room rear (in)57.457.457.457.457.457.4
Legroom front (in)414141414141
Legroom rear (in)40.840.840.840.840.840.8
Passenger volume (cu ft)158.4158.4158.4158.4158.4158.4
Roof rail static load capacity lb165165165165165165
Shoulder room front (in)61.961.961.961.961.961.9
Shoulder room rear (in)61.761.761.761.761.761.7
Towing capacity lb350035003500350035003500
SportEX-LTrailSportTouringTouring BlackoutElite
Wheel size (in)201818202020
Wheel materialaluminum-alloyaluminum-alloyaluminum-alloyaluminum-alloyaluminum-alloyaluminum-alloy
Wheel finishShark GrayPewter Gray Machine-FinishedShark GrayShark Gray Machine-FinishedBlack AlloysShark Gray Machine-Finished
Tire size255 / 50 R20255 / 60 R18265 / 60 R18 Rugged Terrain255 / 50 R20255 / 50 R20255 / 50 R20
Spare tire––Full-Size–––
SportEX-LTrailSportTouringTouring BlackoutElite
Collision mitigation brakingYesYesYesYesYesYes
Road departure mitigationYesYesYesYesYesYes
Forward collision warningYesYesYesYesYesYes
Lane departure warningYesYesYesYesYesYes
Blind spot informationYesYesYesYesYesYes
Cross traffic monitorYesYesYesYesYesYes
Adaptive cruise controlYesYesYesYesYesYes
Blind spot detectionYesYesYesYesYesYes
Eyesight standardNoNoNoNoNoNo
Pre collision brakingYesYesYesYesYesYes
SportEX-LTrailSportTouringTouring BlackoutElite
Google built-in (3-Years Unlimited Data Plan)YesYesYesYesYesYes
12.3-Inch Color TouchscreenYesYesYesYesYesYes
10.2-Inch Digital Instrument ClusterYesYesYesYesYesYes
Power Lift TailgateYesYesYesYesYesYes
Honda Sensing SuiteYesYesYesYesYesYes
Apple CarPlay and Android Auto CompatibilityYesYesYesYesYesYes
Tri-Zone Automatic Climate ControlYesYesYesYesYesYes
LED Headlights with Auto On/OffYesYesYesYesYesYes
LED Fog LightsYesYesYesYesYesYes
Gloss Black Roof RailsYesYesYesYesYesYes
Dual Gloss Black Exhaust FinishersYesYesYesYesYesYes
Leather-Trimmed Seats with Fabric Accents-YesYesYesYesYes
Multi-Function 2nd-Row with Removable Middle Seat-YesYesYesYesYes
Wireless Phone Charger (Qi)-YesYesYesYesYes
Parking Sensors (4 Front & 4 Rear)-YesYesYesYesYes
Low-Speed Braking Control-YesYesYesYesYes
HomeLink Remote System-YesYesYesYesYes
Automatic-Dimming Rearview Mirror-YesYesYesYesYes
Heated Power Side Mirrors with LED Turn Signals and Reverse Gear Tilt-Down-YesYesYesYesYes
Dual Chrome Exhaust Finishers-YesYesYesYesYes
Panoramic Moonroof with Tilt and Slide Function--YesYesYesYes
Trail Torque Logic--Yes---
TrailWatch Camera System--Yes---
Durable Synthetic Leather with TrailSport Orange Stitching--Yes---
Heated Steering Wheel--Yes--Yes
Underbody Skid Plates with Integrated Front Recovery Point--Yes---
Standard Trailer Hitch Receiver with Rear Recovery Point--Yes---
Power Folding Side Mirrors--Yes---
All-Season Floor Mats (All Rows)--Yes---
Bose Premium Sound System with 12 Speakers---YesYesYes
Hands-Free Access Power Liftgate with Walk Away Close---YesYesYes
Multi-Zone Audio---YesYesYes
Leather-Trimmed Seats---YesYesYes
Gloss Black Front Grille---YesYesYes
Gloss Black Rear Roof Spoiler Sides---YesYesYes
Gloss Black Door Handles---YesYesYes
Black Lug Nuts----Yes-
Gloss Black Emblems (Rear H-Mark, AWD, Pilot, and Touring)----Yes-
Head-Up Display-----Yes
Perforated Leather-Trimmed Seats with Quilted Alcantara Accents-----Yes
Ventilated Front Seats-----Yes
Rear Outboard 2nd-Row Heated Seats-----Yes
Rain-Sensing Windshield Wipers-----Yes
Auto-Dimming Side Mirrors-----Yes
Puddle Lights-----Yes
SportEX-LTrailSportTouringTouring BlackoutElite
Package contents
  • HPD Package
  • Protection Package
  • Function Package
  • HPD Package
  • Protection Package
  • Function Package
  • HPD Package
  • Protection Package
  • Function Package
  • HPD Package
  • Protection Package
  • Function Package
  • HPD Package
  • Protection Package
  • Function Package
  • HPD Package
  • Protection Package
  • Function Package
